ACCESS
R2P® Destination Slender® Guiding Sheath
Enhance your radial access algorithm with the performance of a thin-wall guiding sheath designed for smooth transition1
Radial to Peripheral (R2P) Guiding Catheter
- 6Fr thin-wall guiding sheath, available in 75cm, 85cm, 95cm, 105cm, 119cm and 149cm
- Designed to allow safe and effective support for radial to peripheral interventional procedures
- Features proprietary slender technology which reduces the outside diameter of the guiding sheath while maintaining a large equivalent ID, reducing the potential for spasm and allowing physicians to maintain their typical device algorithm
Additional Resources
Why is a thin-wall guiding sheath important for R2P cases?
A thin-wall guiding sheath is crucial for R2P (radial to peripheral) cases because it enables the delivery of devices through smaller access points while maintaining a large inner lumen. This design allows physicians to use a destination sheath or guiding sheath that supports complex interventions without needing larger arterial access, which reduces the risk of complications. In radial access procedures extending to peripheral targets, a thin-wall guiding sheath optimizes patient comfort and reduces the potential for spasm. It also permits the passage of a guiding catheter with sufficient support and torque response, enhancing precision during challenging radial to peripheral interventions.
| Product Code | Working Length | Total Length | FR size | Tip Shape | Sheath ID | Sheath OD | Dead Space Volume | Max guidewire OD |
| GS-R6ST1C75W | 75 cm | 80 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 4.0 mL | 0.038" (0.97 mm) max |
| GS-R6ST1C85W | 85 cm | 90 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 4.5 mL | 0.038" (0.97 mm) max |
| GS-R6ST1C95W | 95 cm | 100 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 5.0 mL | 0.038" (0.97 mm) max |
| GS-R6ST1C10W | 105 cm | 110 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 5.5 mL | 0.038" (0.97 mm) max |
| GS-R6ST1C12W | 119 cm | 124 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 6.0 mL | 0.038" (0.97 mm) max |
| GS-R6ST1C15W | 149 cm | 154 cm | 6 Fr | Straight | 2.2 mm / 0.087" | 2.5 mm / 0.100" | 7.0 mL | 0.038" (0.97 mm) max |
Related Products
References
RX ONLY. Refer to the product labels and package insert for complete warnings, precautions, potential complications, and instructions for use.
1. Data on file
aThe R2P™ DESTINATION SLENDER™ Guiding Sheath is not intended for discrete placement within the coronary or neuro vasculature
